12ft Offshore Cargo Basket (DNV 2.7-1 / EN 12079 Certified)
The 12ft Offshore Cargo Basket offers an ideal intermediate footprint for offshore oil and gas rigs, subsea installation vessels, and marine support operations. Engineered to carry equipment slightly longer than standard 10ft units—such as drill collars, subs, valves, pipe joints, and heavy rigging assemblies—this open-top basket ensures maximum deck efficiency and instant crane-hook accessibility during high-seas transfers.
Fully certified to DNV 2.7-1 / BS EN 12079 and ISO 10855 international offshore safety standards, each basket is fabricated from heavy-gauge structural steel and finished with high-build marine-grade epoxy paint to withstand severe ocean weathering. Features include integrated corner guide posts for secure deck stacking, continuous perimeter tie-down lashing rings, self-draining floor mesh/ports, an optional drop-down side door for manual access, and a certified DNV 2.7-1 4-leg wire rope sling set with safety bow shackles.
Key Features & Technical Specifications
1. Offshore Certification & Rigging
Offshore Compliance: Fully certified to DNV 2.7-1, BS EN 12079, and ISO 10855 safety standards for dynamic marine operations.
Sling Assembly: Supplied complete with a certified DNV 2.7-1 4-leg wire rope sling set fitted with safety-type bow shackles.
Integral Padeyes: Four heavy-duty, high-tensile steel padeyes integrated directly into the vertical corner frame posts.
Deck Stacking: Built-in corner guide posts enable alignment-guided stacking on supply vessel decks and rig storage areas.
2. Structural Design & Cargo Protection
Intermediate Footprint: Provides extra clearance over 10ft models without taking up the deck area of a 20ft container.
Access & Drainage: Integrated floor drainage ports to prevent standing water, with optional side-wall drop-down gates for ergonomic manual loading.
Internal Tie-Downs: Heavy-duty internal lashing points along floor and side rails to lock down loose cargo during rough sea transit.
Corrosion Protection: Shot-blasted structural steel frame treated with zinc-rich epoxy marine primer and polyurethane topcoat.
3. Dimensions & Weights
Parameter | Metric Specifications | Imperial Specifications |
External Length | 3,658 mm | 12' 0" |
External Width | 1,220 mm / 2,438 mm | 4' 0" / 8' 0" |
External Height | 1,200 mm / 1,400 mm | 3' 11" / 4' 7" |
Internal Length | 3,490 mm | 11' 5.4" |
Internal Width | 1,060 mm / 2,280 mm | 3' 5.7" / 7' 5.7" |
Internal Height | 950 mm / 1,150 mm | 3' 1.4" / 3' 9.3" |
Tare Weight | Approx. 1,800 kg | 3,968 lbs |
Max Payload | Approx. 5,700 kg | 12,566 lbs |
Max Gross Weight | 7,500 kg | 16,534 lbs |
