40ft High Cube (HC) Mobile Mining Workshop Container

40ft High Cube (HC) Mobile Mining Workshop Container

R 380 000,00 Regular Price
R 350 000,00Sale Price
Quantity

New Build / Custom Industrial Fit-Out (One-Trip Base Container)

Engineered for remote mining sites, harsh ambient environments, and heavy-duty mechanical servicing, providing a secure, transportable, and fully self-sufficient workspace.

2. Dimensions & Capacities

Parameter

Metric (SI)

Imperial

External Length

12,192 mm

40 ft 0 in

External Width

2,438 mm

8 ft 0 in

External Height

2,896 mm (High Cube)

9 ft 6 in

Internal Length

~12,032 mm

39 ft 5 in

Internal Width

~2,352 mm

7 ft 9 in

Internal Height

~2,690 mm (High Cube)

8 ft 10 in

Personnel Door Opening

~900 mm W x 2,050 mm H

3 ft 0 in x 6 ft 8 in

Roller Shutter Opening

~2,400 mm W x 2,200 mm H

7 ft 10 in x 7 ft 3 in

Internal Volume

~76.2 $m^3$

2,690 $cu\ ft$

Tare Weight (Est.)

~6,500 kg (Dependent on fit-out)

~14,330 lbs

Max Gross Weight (MGW)

30,480 kg

67,200 lbs

3. Material & Structural Specifications

  • Steel Construction: Corrugated Corten A-grade weathering steel exterior shell, structurally reinforced around all cutouts for doors, roller shutters, and ventilation.

  • Frame & Corner Castings: ISO 1161 heavy-duty corner castings for standard twist-lock handling, crane lifting, and multi-modal transport.

  • Flooring: Heavy-duty 4mm steel checker plate (or marine-grade plywood overlaid with industrial anti-slip vinyl), engineered to handle heavy point loads, dropped tools, and high foot traffic.

  • Insulation & Lining: 50mm high-density rockwool or polyurethane spray-foam insulation behind internal white-melamine or galvanized steel wall/ceiling panels for extreme thermal regulation.

4. Security & Access Features

  • Primary Access: Heavy-duty steel personnel access (PA) door fitted with heavy-duty mortise deadlocks and a weather-sealed frame.

  • Equipment Access: Aluminum or galvanized heavy-duty side-mounted roller shutter door with dual slide-bolt locks for loading bulky parts or creating cross-ventilation.

  • Secure Storage: Lockable internal tool cages/partitions constructed from heavy-gauge expanded metal or steel mesh to protect high-value diagnostic equipment.

  • External Security: Factory-welded steel lockboxes on original container cargo doors (if retained at the rear end for bulk storage).

5. Electrical & Safety Infrastructure

  • Power Distribution: Industrial DB switchboard equipped with RCD protection, main isolator, and external 3-phase or heavy single-phase site-plug inlet (IP66 rated).

  • Lighting: High-output, dust-proof LED strip or batten task lighting running the length of the workspace.

  • Power Outlets: Strategically placed IP66-rated weather-resistant GPOs along workbench areas for heavy power tools, welders, and battery chargers.

  • Climate Control: Industrial-grade split-system air conditioner (reverse cycle) sized for extreme external ambient temperatures.

  • Safety Compliance: Integrated emergency eyewash station, heavy-duty chemical spill kit, fire extinguisher mounting points, and optional bunded flooring for fluid management.

6. Logistics & Handling

  • Transport: Fully CSC-plated base container, transportable via standard container side-loaders, flatbed trucks, or tilt-trays.

  • Site Deployment: Designed for rapid plug-and-play hookup to on-site generator or grid power, with integrated lifting lugs and forklift pockets (where specified).
