The 53ft Offshore Cargo Basket represents the ultimate solution for transporting extra-length casing, drill pipe, jointed tubing, risers, and large subsea assemblies to offshore oil and gas rigs and deepwater platforms. Engineered specifically for ultra-long cargo that cannot fit into standard 20ft or 40ft units, this 53-foot basket provides uncompromised structural integrity and crane-lifting safety during high-seas operations.

Fully certified to DNV 2.7-1 / BS EN 12079 and ISO 10855 international offshore standards, each unit is fabricated from heavy-gauge structural steel and finished with high-build zinc-rich marine epoxy paint for maximum salt-spray protection. Designed with corner guide posts for safe deck alignment, internal tie-down lashing points along the floor and side rails, and self-draining flooring, it comes complete with a certified DNV 2.7-1 4-leg wire rope sling set with safety bow shackles.

Key Features & Technical Specifications

1. Offshore Certification & Rigging

• Offshore Compliance: Certified to DNV 2.7-1, BS EN 12079, and ISO 10855 safety standards for dynamic offshore crane operations.

• Sling Assembly: Supplied with certified DNV 2.7-1 4-leg wire rope sling set with safety-type bow shackles.

• Integral Padeyes: Four heavy-duty, high-tensile steel padeyes integrated into the main corner structural posts.

• Deck Stacking: Reinforced frame with corner guide posts for alignment-guided stacking on supply vessel decks.

2. Extra-Long Frame & Cargo Security

• 53ft Structural Span: Maximize deck efficiency by transferring long-joint tubulars, casing, and drill strings in a single lift.

• Drainage & Access: Integrated floor drainage ports to prevent standing water, with optional side-wall drop-down gates for ergonomic manual access.

• Internal Tie-Downs: Heavy-duty lashing rings positioned along the internal perimeter to lock down high-value equipment.

• Corrosion Coating: Shot-blasted steel frame treated with multi-layer marine-grade primer and topcoat.

3. Dimensions & Weights
